X20CP1485 – Technical Specifications & Applications

Technical Specifications

General

• Supply voltage: 24 VDC (-15% … +20%)

• Max. input current: 2.2 A

• Power consumption: approx. 10.5 W

• Cooling: Fanless, convection cooling

• Dimensions (W×H×D): 150 × 99 × 85 mm

• Weight: approx. 0.665 kg

• Operating temperature: 0 … 55 °C

• Storage temperature: -40 … 85 °C

• Humidity: 5–95% RH (non-condensing)

• Protection: IP20

• Mounting: DIN rail

Processor & Memory

• Processor: Intel Celeron 400

• DRAM: 32 MB

• Retainable SRAM: 1 MB

• Application memory: External CompactFlash (CF) card slot (not included)

• Real-time clock (RTC): Integrated with battery backup

Interfaces

• 1 × ETHERNET Powerlink (real‑time industrial Ethernet)

• 1 × 10/100 Base‑T Ethernet (programming/IT communication)

• 1 × RS232

• 2 × USB 2.0

• 1 × slot for X20IF interface module (fieldbus expansion: Profibus, CAN, etc.)

• X2X Link backplane bus (high‑speed I/O connection)

Features

• LED status indicators: Power, CPU, CF card, Ethernet, POWERLINK, battery, overtemperature

• Reverse polarity protection

• Non‑replaceable internal fuses

• Shortest task cycle time: 400 µs

• Certifications: UL, cULus, cCSAus, DNV, CCS, LR, KR, ABS, BV, KC

Applications

• Machine tools & metal processing

• Packaging & printing machinery

• Production line automation

• Motion control systems

• New energy & solar equipment

• Process control in hazardous locations (Class I, Division 2, Groups ABCD, T5)B& R Industrial Automation

• High‑speed I/O & data acquisition
